| MOQ: | 1 UNIT |
| Price: | $15,900.00/sets 1-2 sets |
| Standard Packaging: | Exporting Standard |
| Delivery Period: | 25 days |
| Payment Method: | TT |
Aotong Trailer-Recommonded Manufacturer Customerize and OEM Service Available | ||||||
Product Name | 2 axles lowbed semi trailer | 3 axles lowbed semi trailer | 4 axles lowbed semi trailer | |||
Model | LAT9190TDP | LAT9320TDP | LAT9321TDP | |||
Size | 12500*3000*1100 (mm) | 13000*3000*1100 (mm) | 14000*3000*1100 (mm) | |||
Payload | 40000KG | 60000KG | 80000KG | |||
Plate | 4mm checked plate | 4mm checked plate | 5mm checked plate | |||
Axles | 2 * 13ton capacity (Brand optional) | 3 * 13ton capacity (Brand optional) | 4 * 13ton capacity (Brand optional) | |||
Ladder | Mechanical spring ladder or hydraulic ladder | |||||
Main beam | Heavy duty I beam. | |||||
Side beam | 250mm I beam | |||||
Suspension | Mechanical suspension (Air suspension optional) | |||||
Leaf spring | 10pcs | |||||
Tire | 12R22.5 / 11.00R20 8pcs (Other size optional) | |||||
Rim | 9.00-22.5 / 11.00R20 8pcs (Other size optional) | |||||
Kin pin | 2’’/3.5’’ bolt type | |||||
Landing gear | 28 Ton two speed | |||||
Braking system | Double air chamber ,brake valve,45L air tanks ;ABS optional | |||||
Electrical | LED light , 7 ways ,24V | |||||
Painting | Sand blasting processing clean rust | |||||
1 coat of anticorrosive primer | ||||||
2 coats of finish urethane paint | ||||||
Color as customer choice | ||||||
Accessory | One tooling box with a set of standard trailer tool | |||||
Usage | Is applicable for the transportations of the mechanical equipment, | |||||
large objects, highway construction equipment, large tanks, | ||||||
power plant equipment or machine, and all sorts of steel products. | ||||||
Other Descriptions | The cargo platform is lower than others, | |||||
is applicable for unsound road condition, | ||||||
ensuring the stablenessof the transportation. | ||||||
Other Specifications | It's concave structured with tyre appeared style, | |||||
the height of the cargo's carrying platform from ground is 900mm, | ||||||
(ladders belong to optional components), with the overall height of 1710 mm | ||||||
Remark | We can design model according to client's requirement | |||||
