Juyuan Trailer Steel 3 Axles Anhydrous Ammonia LPG Gas Tanker Semi Trailer

Products

Farm Trailer & Other Full Trailer

Juyuan Trailer Steel 3 Axles Anhydrous Ammonia LPG Gas Tanker Semi Trailer

MOQ:	1 UNIT
Price:	$20,000.00/units 1-2 units
Standard Packaging:	In nude,Polish with water wax before shipment 1 By 40ft/45ft/40fr container 2 By bulk /roro ship 3 As your requirments. Professional package saves freight cost for customers Guarantee the firmness and safety of the goods
Delivery Period:	25 days
Payment Method:	TT
Supply Capacity:	500 Unit/Units per Month lpg semi trailer

Detail Information

Product Description

Detail Information

Place of Origin

CHINA

Brand Name

AOTONG

Certification

ISO,CCC

Use:

Truck Trailer

Type:

Semi-Trailer

Material:

Steel

Size:

13000*2500*3990mm

Max Payload:

30TONS

Application:

Transport Liquid Petrol Gas

AXle No.&Brand:

3; BPW

Tire:

12R22.5 Double Coin

Suspension:

Air Suspension

Brake System:

Dual Line Braking System

Color:

Custom's Requirement

Design Pressure:

1.61Mpa

Volume:

Optional

OE NO.:

Juyuan Trailer

Port:

Tianjin/ Lianyungang/Qingdao/Shanhai Port

Product Description

Hot sale 3 axles high quality anhydrous ammonia lpg transport trailer lpg semi trailer lpg gas tanker semi trailer

Product details

Juyuan Trailer Steel 3 Axles Anhydrous Ammonia LPG Gas Tanker Semi Trailer 0

1>High quality steel makes trailer itself lighter but strong enough for heavy cargos, so that transport company can load more tons.

2>The most skilled workers make welding of this fuel tank trailer more frequent and strong.

3>Two pieces spare tire carriers, water tank, fuel tank, extinguisher etc, are optional accessories which build modern transportation.

Dimensions(lengthwidthheight)	1298225003990(mm)
Estimated Tare Weight	16396KG
Payload	23604KG
Total Weight	40000KG
Effective Volume	56.2CBM
Shell Of Tanker
Products	LPG, Butane , Propane
Fluid property	flammable
Design temperature	-40°C to 50°C
Design pressure	1.61MPa
Corrosion allowance	1.0mm
Major materials of bearing pressure	Tanker body : Q345R , 12.5mm
	End plate : Q345R , front:10mm,Rear:12.5mm
	Main Beam : T700
Filling weight per volume	420Kg/m3
Maximum filling weight	24486Kg
Compartments	One
Baffle inside the tank	14-off Aluminum bolted plate , thickness is 5mm
Shape	Cylindrical ; Ellipse head
Detection
Heat treatment	Overall heat treatment in a furnace , 500°C to 560°C
Flaw detection	100% Flaw detection
Hydrostatic test	2.1MPa
Magnaflux	Aim at welding place flaw detection can not cover
Manhole (As customer's requirement )
Quantity	1 ; On top
Safety Valve (As customer's requirement )
Quantity	Two
Location	On the top of tanker ;
Type	Only weld suitable flange
Size	As customer's requirement
Liquid meter (As customer's requirement )
Quantity and Model	1
Location	On left side of tanker
Type	Only weld suitable flange
Size	As customer's requirement
Valve and pipe Detail (As customer's requirement )
Running System
Axles	3	13 TON FUWA Axles
Suspension system	1	Leaf spring
Wheel rim	12	9.00
Tyre	12	Brand : Triangle,1100 rail tire
Kingpin	1	90#
Landing legs	1	28Ton FUWA
Pneumatic Brake System
Spring brake chamber	6	FUWA
Air connector	1	FUWA
Relay Valve	1	BRAND:WABCO
ABS	1	WABCO ABS
Electronical System
7-Pin Socket	1	24V 7-pin socket
LED Lamp	1	All kinds of lamp
Cable	1	Stander cable

Juyuan Trailer Steel 3 Axles Anhydrous Ammonia LPG Gas Tanker Semi Trailer 2
